DIXON ST系列液壓接頭 ST Series Hydraulic Couplings
ST SERIES

Dixon Quick Couplings
Dixon快速接頭
ST Series
ST系列

DIXON ST系列液壓接頭 ST Series Hydraulic Couplings技術選型資料下載
ST SERIES Dixon Quick Couplings Dixon快速接頭

Product Options產品選項:

FNPT & FBSPP threads (1/4” to 3/8”)
FNPT & FBSPP 螺紋(1/4” 至 3/8”)
FNPT, FBSPP & ORB threads (1/2” to 2”)
FNPT, FBSPP & ORB 螺紋(1/2” 至 2”)
氧氣清洗Oxygen cleaning
鎖緊套筒Locking sleeve

密封件材質Seal Material:

Seal material options (Viton?, EPDM, Mil-Nitrile, Kalrez?
密封材料選項 (Viton?, EPDM, Mil-Nitrile, Kalrez?)
尺寸 1/4” 至 2”
Body Materials: High Tensile steel and 316 stainless steel
材質 高強度鋼和316不銹鋼

標準Standards： 符合挪威船級社接頭應用標準Det Norske Vertias (DNV) compliant for coupling applications

通用（互換）Interchange： Snap - Tite 71 系列 Snap - Tite 71 Series

市場&應用Markets & Uses

1、石油平臺（液壓供給管線，鉆井架，夾鉗，升降裝置和傳動鋼絲繩控制裝置，頂部控制裝置）Oil Platforms (Hydraulic supply lines, rig, tongs, jackup lifts & control shack line, top drives)
2、建筑施工設備（打樁設機，夯土機，地下鑿巖機）Construction equipment (Pile-Drivers, tampers, underground boring hammers)
3、海上工程（液壓工具和繞線車）Offshore (Hydraulic tools & supply reels)

特點Features:

Machined components manufactured using solid steel or 316 stainless bar stock
部件使用脫氧實心鋼或316不銹鋼棒料機加工制成
Stainless steel balls, retaining rings and spring maximize corrosion resistance & extend service life
不銹鋼滾珠，定位環和制動彈簧均為不銹鋼以確保最大程度的防銹，延長使用壽命
Steel componentry is plated using ROHS Compliant Trivalent Chrome
鋼制部件使用符合ROHS標準的三價鉻電鍍
Steel coupler sleeves are hardened to resist deformation & maximize service life
鋼制接頭套管經硬化處理以防止變形，延長使用壽命
Steel nipples are hardened to provide heavy duty performance
鋼制軟管接頭接頭經硬化處理使其具有高強度性能
All couplers and nipples incorporate PTFE anti-extrusion rings to protect the seal
components from dynamic impulse damage.
所有接頭和軟管接頭都內置聚四氟乙烯 抗擠壓擋圈以保護密封件免受動態沖擊損壞。

DQC ST-Series Snap-Tite 71 Interchange Female Coupler

Select a Product

DQC ST-Series Snap-Tite 71 Interchange Female Plug

Select a Product

DQC ST-Series Snap-Tite 71 Interchange Dust Plug

Product Information
Material: Aluminum
Select a Product
Part Number
Body Size
2STDP-A 1/4"
3STDP-A 3/8"
4STDP-A 1/2"
6STDP-A 3/4"
8STDP-A 1"
8STDP-A-V2 1"- V2
16STDP-A 2"
